Camera
|
Image Sensor
|
1/4" progressive scan CMOS
|
Min. Illumination
|
Color: 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR
|
Shutter Speed
|
1/3 s to 1/100, 000 s, support slow shutter
|
Lens
|
2.8 mm @F2.2, horizontal field of view 92°, 4 mm @F2.2, horizontal field of view 70°
6 mm @F2.2, horizontal field of view 56°
|
Lens Mount
|
M12
|
Day &Night
|
IR cut filter with auto switch
|
3-Axis Adjustment
|
Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360°
|
DNR (Digital Noise Reduction)
|
3D DNR
|
WDR (Wide Dynamic Range)
|
Digital WDR
|
Compression Standard
|
|
Video Compression
|
Main stream: H.264
Sub stream: H.264/MJPEG
|
H.264 Type
|
Baseline Profile/Main Profile
|
Video Bit Rate
|
32 Kbps to 2 Mbps
|
|
Max. Resolution
|
1280 × 720
|
Main Stream
Max. Frame Rate
|
50Hz: 25fps @(1280 × 720)
60Hz: 30fps @(1280 × 720)
|
Sub-stream
Max. Frame Rate
|
50Hz: 25fps @( 640 × 480, 352 × 288, 320 × 240)
60Hz: 30fps @( 640 × 480, 352 × 240, 320 × 240)
|
Image Settings
|
Brightness, saturation, contrast, sharpness are adjustable via web browser or client software
|
Day/Night Switch
|
Support auto, scheduled
|
Others
|
Mirror, BLC (area configurable), region of interest (support 1 fixed region)
|
Network
|
Detection
|
Motion detection
|
Alarms
|
Video tampering, network disconnected, IP address conflicted
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour
|
Standard
|
ONVIF (PROFILE S, PROFILE G), ISAPI
|
General Function
|
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
|
Interface
|
|
Communication Interface
|
1 RJ45 10M/100M self-adaptive Ethernet port
|
General
|
Operating Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
|
Power Supply
|
12 VDC ±25%, PoE (802.3af)
|
Power Consumption
|
Max. 3.5 W/5.5 W (PoE)
|
Ingress Protection
|
IP67
|
IR Range
|
Up to 30 m
|
Dimensions
|
Φ 85.5 mm × 70 mm (3.38" × 2.76")
|
Weight
|
350 g (0.77 lb.)
|
|
