DS-7104HGHI -F1

Turbo HD DVR

H.264 /H.264+& Dual-stream video compression
Support both HD-TVI /analog and AHD cameras with adaptive access
Full channel recording at up to 1080P lite resolution
HDMI and VGA output at up to 1920×1080P resolution
Long transmission distance over coax cable
Support 4-ch synchronous playback at 720P resolution

THÔNG SỐ KỸ THUẬT
BÌNH LUẬN

Video/Audio Input
Audio Input:		1-ch
Video Compression:		H.264,H.264+
Analog Video Input:		4-ch
Analog and HD-TVI video input:		4-ch,BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
Audio Compression:		G.711u
Two-way Audio:		1-ch RCA(2.0Vp-p, 1kΩ)

Video/Audio Output
HDMI/VGA Output:		1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
Encoding resolution:		When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF
Frame Rate:		Main stream: When 1080p Lite mode not enabled: For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) Sub-stream: 2CIF@6fps; CIF/QVGA/QCIF@ 25fps (P)/30fps (N)
Video Bit Rate:		32 Kbps ~ 4 Mbps
Stream Type:		Video/Video&Audio
Audio Output:		1-ch RCA(Linear, 1kΩ)
Audio Bit Rate:		64kbps
Dual Stream:		Support
Synchronous Playback:		4-ch

Network management
Remote connections:		32
Network protocols:		TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

Hard Disk Driver
Interface Type:		1 SATA Interface
Capacity:		Up to 6 TB capacity for each disk

External Interface
Network Interface:		1; 10M / 100M self-adaptive Ethernet interface
USB Interface:		2 USB 2.0 Interfaces

General
Power Supply:		12 VDC
Consumption:		≤ 8 W
Working Temperature:		-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working Humidity:		10% to 90%
Dimensions:		200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
Weight:		≤ 0.8 kg (1.8 lb)
